DIN Handle Type Viscosity Cup

DIN Handle Type Viscosity Cups designed for precise fluid flow measurement. Available in 2mm, 4mm, 6mm, and 8mm hole diameters, covering viscosity ranges from 15 cst to 3000 cst. Ideal for industrial and laboratory use.

The DIN Handle Type Viscosity Cup is designed according to DIN 53211 standards, providing precise and reliable flow measurements for fluids with different viscosities. These cups are specifically tailored with a handle for easy handling and accurate measurements, making them perfect for laboratory or industrial use. The cups feature varying hole diameters (from 2mm to 8mm) to accommodate different fluid viscosities, from low to high.

Each cup is designed to measure the flow time of a fluid by timing how long it takes for the fluid to flow through the hole once it is opened. The results, which are expressed in seconds, allow for the determination of the fluid’s viscosity based on the flow rate, which is helpful for applications such as coatings, paints, resins, and other chemical products.

These DIN handle-type cups are highly accurate and widely used for fluid flow measurement in accordance with DIN53211 standards.

Technical Specifications:

Order Code	Standard	Type	Hole Diameter	Viscosity Range	Flow Time
V30102	DIN53211	DIN Handle Type	2 mm	15-30 cst	25-150 sec
V30104	DIN53211	DIN Handle Type	4 mm	112-658 cst	25-150 sec
V30106	DIN53211	DIN Handle Type	6 mm	550-1500 cst	25-150 sec
V30108	DIN53211	DIN Handle Type	8 mm	1200-3000 cst	25-150 sec
